An electrical equivalent circuit to simulate the output power of an AlGaAs/GaAs planar gunn diode oscillator

Cumming, David R.S.; Thomas, Dave; Maricar, Mohamed Ismaeel; Khalid, Ata; Dunn, Geoff; Greedy, Steve; Thomas, David W.P.; Cumming, David R. S.; Oxley, Chris H.

An electrical equivalent circuit to simulate the output power of an AlGaAs/GaAs planar gunn diode oscillator Thumbnail


Authors

David R.S. Cumming

Dave Thomas

Mohamed Ismaeel Maricar

Ata Khalid

Geoff Dunn

David W.P. Thomas

David R. S. Cumming

Chris H. Oxley



Abstract

© 2018 Wiley Periodicals, Inc. The planar Gunn diode offers the potential of microwave, milli-metric and THz-based oscillators, which can be fabricated as part of a microwave monolithic integrated circuit (mmic). The paper develops an electrical representation of an aluminum gallium arsenide (AlGaAs) based planar Gunn diode with an active channel length of approximately 4 μm and width of 120 μm, embedded in an oscillator circuit. The work indicates a maximum simulated RF output power of +5 dBm compared with published experimental results of −19 dBm for similar diodes.
