Vector control strategies to enable equal frequency operation of the modular multilevel matrix converter

Diaz, Matias; Espinoza, Mauricio; Rojas, Felix; Wheeler, Patrick; Cardenas, Roberto

Abstract

The Modular Multilevel Matrix Converter (M3C) is an ac-to-ac converter suitable for high-power applications. The control of this converter is complex, mainly when the frequencies of the ac systems connected to the ports of the converter are close or equal, because the floating capacitors can present large voltage oscillations. Therefore, this paper proposes a new Vector Control System to enable the operation of the M3C when the input-output frequencies are equal. The effectiveness of the proposal is validated through simulations and experimental results conducted with a 27 power-cell prototype.

Citation

Diaz, M., Espinoza, M., Rojas, F., Wheeler, P., & Cardenas, R. (2018, April). Vector control strategies to enable equal frequency operation of the modular multilevel matrix converter. Presented at 9th International Conference on Power Electronics, Machines and Drives (PEMD 2018), Liverpool, UK

• Presentation Conference Type: Conference Paper (published)
• Conference Name: 9th International Conference on Power Electronics, Machines and Drives (PEMD 2018)
• Start Date: Apr 17, 2018
• End Date: Apr 19, 2018
• Acceptance Date: Feb 14, 2018
• Publication Date: Apr 19, 2018
• Deposit Date: May 1, 2018
• Publicly Available Date: May 1, 2018
• Peer Reviewed: Peer Reviewed
• Keywords: Modular multilevel matrix converter; Equal frequenciesoperation; Floating capacitor voltage control
• Public URL: https://nottingham-repository.worktribe.com/output/926811
• Publisher URL: https://ieeexplore.ieee.org/document/8737061
• Related Public URLs: https://www.psma.com/events/2018-iet-9th-international-conference-power-electronics-machines-drives-pemd
• Additional Information: © 2019 IEEE. Personal use of this material is permitted. Permission from IEEE must be obtained for all other uses, in any current or future media, including reprinting/republishing this material for advertising or promotional purposes, creating new collective works, for resale or redistribution to servers or lists, or reuse of any copyrighted component of this work in other works.
• Contract Date: May 1, 2018
